Technical details     SLS34-SM


    ALU+ limited


  • Surface mounted louvre with a pitch of 34mm.
  • All profiles are manufactured from aluminium extrusions.
  • Z-shaped louvre blades.
  • ¬†Frame profiles with a total height of 35 mm.


  • Aluminium - all parts (frame profile, clips and blades) are manufactured from aluminium extrusions Al Mg Si 0,5 (6063 T6)
  • Profile thickness: minimum 1.0 mm.

Finish :

  • Natural anodised15-22micron
  • Polyester powder coated - BS6496
  • Powder coating in any RAL or B/S colour available
  • Thickness of powder coating 40 micron minimum

Protection :

  • Fibre glass insect mesh fitted as standard.
  • Other meshes available as an option
  • A reinforcement profile carrying extra blade supports is fitted when the width of the louvre is > 700mm.


  • The wall louvre consists of an angled box frame profile.
  • The aluminium louvre clips are glided into the frame profile. The aluminium louvre blades are clipped into the louvre clips.
  • The blade pitch is 34mm & the visual free area is 64%.
  • Aluminium water drainage profile can be fitted at the bottom of the louvre to ensure better water tightness.


Custom made by our skilled Craftsmen to your exact requirements
